[TC Webinar] Low-Carrier-Ratio Modulation and Control Strategies for Dual Three-Phase Permanent-Magnet Synchronous Motor Drives

Wednesday 16 July 2025 at 8:00 PM CST, 2:00 PM CET, 8:00 AM EST

By Zheng Wang (School of Electrical Engineering, Southeast University, China)

Register now using the link below:

https://attendee.gotowebinar.com/register/663814100366350425

Abstract:

With increasing requirements of high power ratings and high reliability in electrified transportation and energy harvesting applications, multiple three-phase permanent-magnet drives, such as the dual three-phase permanent-magnet synchronous motor (DTP-PMSM) drives have attracted more attentions in both academia and industry. For high-power or high-operation-frequency motor drives, the carrier ratio, i.e., the ratio of switching frequency versus fundamental frequency, is low. Such low-carrier-ratio operation brings challenges in large low-order harmonics, distinct control delay and coupling effects between d-axis and q-axis to control of DTP-PMSM, which suffers from much smaller inductances in harmonic subspace and more numbers of switching states. For addressing the issues and improve the control performance of DTP-PMSM with low carrier ratios, this webinar will investigate multiple advanced low-carrier-ratio modulation and control schemes for DTP-PMSM drives. The modulation schemes under investigation include multisampling space vector modulation (MS-SVM), selective harmonic elimination pulse width modulation (SHEPWM), and synchronous optimal pulse-width modulation (SOPWM), whereas the control schemes include complex vector based control, model predictive control (MPC), and flux trajectory control-based model predictive pulse pattern control (MP3C). The theoretical principles and experimental results will be presented to compare different control strategies for DTP-PMSM drives with low carrier ratios.

Presenter’s bio:

Zheng Wang received the B.Eng. and the M.Eng. degrees from Southeast University, Nanjing, China, in 2000 and 2003, respectively, and the Ph.D. degree from the University of Hong Kong, Hong Kong, in 2008, all in electrical engineering. From 2008 to 2009, he was a Postdoctoral Fellow in Ryerson University, Toronto, ON, Canada. He is currently a Professor in the School of Electrical Engineering, Southeast University, China.
His research interests include electric drives, power electronics and their applications. In these fields, he has authored over 150 internationally refereed papers, 1 English book by IEEE-Wiley Press, and 2 English book chapters. Prof. Wang received IEEE PES Chapter Outstanding Engineer Award. He is an IET Fellow and an IEEE VTS Distinguished Lecturer. He served as an associate editor of IEEE Transactions on Industry Applications and IEEE Transactions on Industrial Electronics.
